Holiday Project, A DIY CNC Adventure

January 16th, 2017 3 Comments

This past holiday break, I have mostly stayed in the garage – setting up a CNC machine and cutting all the things that I deemed cuttable by it.

Raymond is busy on CNC jobs

Owning a CNC machine has been on my list for a long time, it is just out of my price range for a high quality professional grade machine, or maybe not useful enough for a “toy” level DIY one. But every time I built an electronic toy, like Pac-Man on a String, I wished to have a precision CNC machine to build a case for it. Recently, a casual chat with Jeremy (@jrwashley) brought up the topic of DIY CNC, I was encouraged to try to build one now, otherwise, it would just be a spot on the wish list.

I researched on the landscape of CNC, primarily focused on entry level to mid-level DIY types.  You can find lots of “CNC Routers” on Amazon, with price range of $400 – $800, but be aware that the controller is antique and requires a old desktop PC with parallel ports. You can also find many CNC DIY builds on Instructables.com, which gives you good ideas on all the elements making up the machine, but may take a while to source or custom-make the parts, with possible fitting issues of parts from difference places. Many of the entry level CNC machine can do light engraving and cutting on softer materials, but will have difficulties in precision cutting harder materials. The ready-made mid-level CNC machine can handle most of jobs better, but it could easily run over $5,000, such as the ShopBot ones.

Choose it.

The machine capabilities and quality are usually correlated to the price tags, so I have to ask what I really need, in order to keep the price in reasonable range while it can do a decent job. If you are in market for a CNC machine, you probably should think along the same lines too. Here is what I laid out:

  1. Mostly work with acrylic and plastic materials, some decent-size wood work, and occasionally aluminum sheets;
  2. Good size of work area for a desktop/bench-top, from 10′ to 20′ in X, Y axis;
  3. Want to have solid structure to ensure the precision and strength of cuts, and the durability of machine itself;
  4. Controller is less of a concern for me, as I will likely replace it later with my own experimental controller, but I do want to have it work with my current computer instead of going back old parallel ports;
  5. Controller, CAD and CAM software; capability and open source?
  6. For now, I want to have good capable CNC machine that I can use immediately, instead of figuring out how a CNC machine is built. So that I can learn to operate the machine, without complication of build issues. After that, I may come back to make a inexpensive DIY CNC machine or other installation from such control mechanism.

With above considerations, it is clear that I would get a kit where all parts come from the same vender (so no mis-match), but I still get the chance to look at all the parts (to understand the purpose of all the parts), and to assemble all the parts into the machine (to understand the machine composition). That will enable me to build my first CNC machine with less potential problems (also to isolate machine issues from operation issues during learning stage), while still get the great ins-and-outs of a CNC machine that I can potentially design my own version in the future. Two equal candidates surfaced: Shapeoko 3 from Carbide 3D, and X-carve from Inventables. I like Inventables for it is an open system and has great resources, but the solid XY rails of Shapeoko 3 won out.

Build it.

Shapeoko-3 Parts

If you have prior experience in assembling a CNC machine, the Shapeoko-3 kit may take you several hours to put it together. For me, I really took it slow to examine each part and understand why and how each part is designed, and how the part will function in the final machine.

CNC controller wiring

The controller works as taking G-code commands from your design, and moving the router along X, Y, Z axis precisely to make the cuts. The controller board can be replaced if I want to do further experiments, by using an Arduino running Grbl.

Operate it.

The basic workflow from idea to build:

  1. Sketch up on a napkin 🙂
  2. Transfer your drawing from napkin to a CAD (Computer-Aided Design) program, where you do the engineering or artistic design,
  3. Export the CAD drawing and import to CAM (Computer-Aided Manufacturing) program, where you do the specification of material (type, size, thickness, etc), mill bits (type, size, etc), operation parameters (feed rate, plunge rate, step depth, routing path), and tool-path and cutting order. You should image how the machine would cut from start to end because that’s exactly what you do here to instruct the machine from start to end,
  4. Generate G-code from CAM to be fed to CNC controller software,
  5. CNC cutting or milling exert forces to cut through material, so make sure to hold your stock material securely and take safety precautions,
  6. Start the job and observe – various issues may occur if you are a beginner and doing experiments,
  7. If everything goes well, you get the job done. Polish it up, such as cleaning, sanding, buffing, etc.

CNC in operation

During the first week, I ran into a lot of issues at step 6, and I had to hit the emergency STOP. During the job run, that’s when all the parameters / factors come together, and you have to experiment to find the perfect combination of operational control parameters, for your design on a particular material using various bits for engraving, milling, cutting. It is a large number of different combination, and experience will definitely help.

For example, not all acrylic materials are equal – generally cast acrylic is good for cutting and even milling, but extruded acrylic tends to melt and form a blob at the bit head. You may slow down spindle and increase feed rate to reduce the rubbing, but it could break milling bit if you go that direction too much. You may use larger bits on wood milling (and later sanding and polishing), but probably it is better to do engraving on acrylic as milling may dull the luster effect.

Usually some CAD/CAM software should come with a CNC machine, whether it is free or paid, open source or propriety, to get you started. But after you get a handle on the CNC workflow, you should explore different software packages for CAD and CAM, as different software can provide various capabilities required by your design.

Show samples.

First set of successful cutting and engraving on acrylic:  1. Abstract flower; 2. Spring time – little girl, kitten and butterfly.

Engraving V-cut on two types of acrylic material

After experimenting for almost one week, I perfected the operational parameters (spindle, feed rate, plunge rate, material, cut/engrave/mill) and proper bits (bit size, bit shape) for making a batch of gifts for the AppsLab team:

Gifts to AppsLab team members

As apprentices in the OAUX organization, we all know UX design philosophy: Glance, Scan and Commit. And that is represented in this CNC-cut fashion of elements:

UX design “elements”

If you still remember from high school chemistry, they are elements from periodic table: Gallium (Ga for Glance), Scandium (Sc for Scan), and Curium (Cm for Commit). Here is a closeup look at the Gallium with information of element symbol, name, atomic number and atomic weight:

Element: Gallium under pink light

Yeah, engravings on acrylic look better under light. Should I mill a wood-channel and install a LED strip for the display?

Google Home Notifier (Google Home Push Notifications)

December 23rd, 2016 2 Comments

Working in an emerging technologies team has a lot of perks. One of them is to kick the tires of technologies that are about to become mainstream. It also has the somewhat fun privilege to gain interwebz bragging rights or the equivalent of the emblematic/annoying “first” comment that plagued the web forums just a few years ago. Today I have another “first”, a Google Home Notifier to send push notifications.

Among my list of “first”* (afaik) are the following:

Ok, ok. I know. It looks like a sad bragging list. It is, but nevertheless I’m proud of it. This brings me to the latest “first,” but let me back up before I dig into how and why I built this Google Home Notifier.

Two years ago I was lucky enough to be in the first batch of Amazon Echo buyers. That led me to be one of the first to “hack” (here and here) with it, which in turn got me some notoriety with the Amazon Echo team. So I was asked under NDA to review their Alpha SDK. I happily agreed. After playing with it for a few weeks, I had some feedback.  One of my main requests was exactly this: I wanted to be able to send a push notification to the device. Why? Here are some use cases:

The list can grow with more compelling use cases, but when I spoke with the Amazon Echo team they had their very valid concerns. What if this feature got abused by marketers or otherwise? Alexa would become a marketing/PR nightmare with stories of constant blabbing, un-opportunistic announcements, etc. So far it seems they don’t have a roadmap for this feature.

Fair enough. So two years ago at the AT&T Developer Summit Hackathon our team used the Amazon Echo. We wanted to send a notification to it, so our half baked solution was to use the Echo as a bluetooth speaker connected to a mac and use the “say” command. The voice didn’t quite match the Echo’s sultry voice. This was far from ideal from many technical standpoints.

Now Amazon Echo has finally a worthwhile competitor: The Google Home. So while we wait and see if Google will implement push notifications, I created my own and it’s available for anyone. I tested with IFTTT and it works like a charm.

A few drawbacks with my implementation is that you have to run it as a server/service inside your house. It can run on a Raspberry Pi, your pc or a mac. Finally I want to acknowledge that the reason I found out this was possible to do was due to this article that describes how to send a notification using Android. The reason I’m still claiming a “first” with my solution is because it accepts external call events from sites like IFTTT or any other server what can POST a notification.

*I’m happy to stand corrected on all my “first” claims! So if you happen to read this and know of someone or yourself that did it first. Please let me know so I can take a humble pill.



Emotion Recognition at Oracle Maker Faire

December 21st, 2016 2 Comments

Emotibot, an emotion sensing robot.


A few weeks before the first ever Oracle sponsored Maker Faire, I was experimenting with some of the cognitive (vision) recognition APIs available. Google Vision API, Watson Visual Recognition and Microsoft Computer Vision API are some of the biggest players in this field right now.

After testing all of them I found the idea of Microsoft’s CaptionBot really compelling: Upload an image to the CaptionBot and it will try to come up with a coherent caption based on a mashup of three of their cognitive services (Computer Vision API +  Emotion API + Bing Image API). I wrote an iOS app (with it’s own  Swift framework) to consume this mashup and took it for a spin.

I gave my phone to my kids to test the app. They ran around the house and were truly amused by pointing the camera to an object and getting a description.

So when the call to create a project for Oracle Maker Faire with my kids came, we sat down and started brainstorming. The concept was still fresh on their minds; A computer could guess as close as possible to what an object is and even guess a facial expression.

Brainstorming ideas

They came up with a plan and a name: Emotibot, an emotion sensing robot. We drove to the closest Home Depot to find materials. We found an Led Glow Ball Lamp that worked perfectly for the head of our emotion sensing robot.

Staging parts before drilling holes



We used the following materials to build our robot:

The robot worked as follows:

  1. The Ultrasonic Ping sensor detected when someone was close to it (about 10 inches).
  2. The robot started to talk using festival-lite or flite. The mouth servo was synchronized with the flite by counting the words and moving the mouth for each word spoken.
  3. A picture was snapped and submitted to Microsoft Emotion API. The JSON result was parsed and then spoken with flite by Emotibot.
  4. Using the blink(1) USB LEDs the robot changed colors based on the emotion.



Overall the project was a success. I was able to involve my kids and they learned some concepts along the way. If anyone is interested to see the code hit me up in the comments and I might put it on Github.

Color Workshop at the Oracle Maker Faire

December 9th, 2016 Leave a Comment

Workshop preparations

For the last 6 years, each Friday, I have been bringing a mobile painting studio to my kids’ school. Among other things, we work on what I call “color studies” – a set of formal exercises aimed to sharpen one’s sense of color and develop painting skill, just like musical scales, chords and arrpedgios sharpen one’s sense of harmony and develop performance skills. I was originally inspired to offer such level of formalism by work of Josef Albers, and my students and I has been playing with the “color studies” for two years at the school.

Here are some of the students’ color studies:

This slideshow requires JavaScript.

I attended the Oracle Maker Faire with the upper echelon of the students (5th and 6th graders), and our contribution was three-fold: we had an exhibit of our color studies; we taught the color workshop to about eighteen self-selected participants; and I got to rattle from the main stage on the topic of Maker Movement and art while kids kept me company up there.

Exhibit stands ready for a trip from Santa Cruz to Redwood Shores

At the workshop

At the workshop

It was big fun to bring kids, their paintings, and our workshop to the Oracle Maker Fair. Many people talk about work/life balance, I am grateful I get to live it 🙂 My thanks go to the Oracle lore for the event, to friends and family for swinging by to support me, and the workshop participants big and small who showed up and painted their hearts out.

Pac-Man on a String

December 8th, 2016 3 Comments

Oracle hosted the first-ever company co-sponsored Maker Faire event on November 17, 2016.

When I heard of the event, I had something in my mind that I would encourage a group of middle-schoolers to make a game for the event. I have been teaching them occasionally on Arduino, NodeMCU and MQTT concept over some weekends, and this is the perfect opportunity to put them together in a build.

After some brain-storming, we came up with “Pac-Man on a String” concept. And because of the way of this game plays, the player needs to rush to a location and do a quick action, I picked the team name as “JET – React” to describe the game play, (and if you are writing JavaScript at Oracle, you know JET and React).

There are some interesting design points we have put into the build:

So we adapted the game plot of well-known Pac-Man, and changed narratives to collect gems (as Emily likes sparkling gems), and changed ghost to wasp so we can flee or just attack at the spot with precise timing. Coding-wise, it turns out “wasp” is very much like “gem” except it chases player (represented as 5-LED segment).

The modified game story and play mechanism fit very well with the limited control and interface we have. Making a interesting game with just one joystick and one LED strip, that presents serious constraints as what you can work with. But in the end, I think we achieved excellent results.

To make it simple, we coded 5-LED segment (we call it Saber) that a player can move it up and down along the LED strip, and use that to collect a gem or attach a wasp. Most people can align 5-LED to sparkling dot on the strip, right?

To make it challenging (that is to gain high score), we made the scoring logic to require a player has great timing and quick reflexes. First, all the gems and wasps can show up at any location, any moment, for any length of duration (all the parameters are randomly generated). So player has to move fast, and quickly decide what to do when multiple gems/wasps are showing. Second, the Saber has 5-LED segment, and if you use middle LED to collect a gem, you get 100 points; the two LED next the middle one will get you 50 points, and two side LED get you 25 points. So it has great incentive to use the middle LED to do your work, but it is very difficult to move the Saber to the right spot, it requires great skill of timing and anticipation. And finally, the wasp can sting you, but if you are quick enough, you can knock it out before it can sting you, and you gain points, that requires great timing skill. Overall, it takes practice to play this game well.

So here is the team info and game play description:

These are the components and flow for the game build.

The game code is on the Arduino Mega board, where the player moves Saber to collect and attack. The code controls all LED light state at all time, which represents space, gems, wasps, as well as detect the player action, and Saber to gem/wasp collision time. It has scoring logic when detected collision, and sends game events to NodeMCU for reporting.

The code on NodeMCU is to rely game events into CloudMQTT, so that the App on Tablet can get the events, and starts/stops game, or accumulates points. Once a game is over, the score is recorded into Oracle Apex database for keeping the Leader board.

First prototype build, using a wooden tea box:

This is the cleaned up final build, hosting all components in a acrylic box:

This is the close-up look at the inside of box:

Score board and leader board in an Android App:

The game as played out at the Maker Faire. Both adults and kids had a blast!

Update: Here’s a video of the gameplay.
